This 6 Relay board is an output driver board for driving the variety of AC / DC loads like Lights, Buzzer, Motor, Fan or any other similar system from an input device like, Microcontrollers, Raspberry Pi, PLC or even simple Digital circuit. This circuit accepts 5V DC as input trigger for each relay, and activate that particular – corresponding relay.
This way, 6 Relays can be switched on or off individually with an individual input of 5V from any external circuit like digital circuit or Microcontroller like Arduino, Raspberry Pi or even 89C51.
However, this circuit can easily be modified to drive loads like solenoid, motors, lights etc.,
This Relay Driver also comes with onboard 12V & 5V Dc Power supplies, Rectifier & Filter Capacitors so that one can connect a suitable transformer.
This project can be used for School / College Projects as well as in industries.
